FSL 1610-400(L594) NEMA 23(57HS56-3004A-123)JKL

FSL 1610-400(L594) NEMA 23(57HS56-3004A-123)JKL Specification

Connection
Four-wire connection for Stepper Motor, Standard terminal block interface

Accuracy
High Precision, Lead Error 0.05 mm/300 mm

Function
Linear Motion Drive for CNC/Automation

Size
594 mm length (overall), Stepper Motor NEMA 23 (57mm x 56mm)

Mounting
Standard mounting holes on base

Operating Voltage
Suggested 24V DC for stepper driver

Frame Material
Aluminum Alloy

Motor Type
2-Phase Hybrid Stepper Motor

Motor Rated Current
3.0A/Phase

Model
FSL 1610-400(L594) NEMA 23(57HS56-3004A-123)JKL

Lubrication
Greased, maintenance required periodically

Ambient Temperature Range
-10C to +50C

Screw Pitch
10 mm per revolution

Step Holding Torque
1.26 Nm (Typical for 57HS56-3004A-123)

Step Angle
1.8

Lead Screw Type
T8 (16 mm diameter, 10 mm lead)

Protection Class
IP20

Drive Length
400 mm travel (effective stroke)
