FSL 1610-450 STROKE WITH NEMA 23 (57HS56-3004A-123)JKL

FSL 1610-450 STROKE WITH NEMA 23 (57HS56-3004A-123)JKL Specification

Connection
NEMA 23 Stepper Motor (57HS56-3004A-123), 4-wire connector

Pressure
Not applicable (mechanical actuator, not pneumatic/hydraulic)

Accuracy
High positioning accuracy, repeatability (up to 0.01mm, typical for this configuration)

Function
Linear Actuator with Motorized Lead Screw

Size
Lead Screw 16mm diameter, 10mm pitch, Stroke 450mm

Mounting
Standard end supports with shaft coupling

Step Angle
1.8 per step

Repeatability
0.01 mm

Maximum Speed
Up to 100mm/sec (application dependent)

Application
CNC automation, 3D printing, robotics, XY table positioning

Operating Voltage
Typical 24-48V DC (depends on driver and setup)

Motor Type
NEMA 23 Stepper Motor (57HS56-3004A-123)

Recommended Driver
Microstepping driver compatible with 3.0A/phase

Rated Current
3.0A per phase

Holding Torque
1.26 Nm

Protection Class
Standard, not waterproof (additional sealing available on request)

Ambient Temperature
-10C to +50C

Lead Screw Specifications
16mm diameter, 10mm pitch, precision machined

Screw Material
High-grade alloy steel

Stroke Length
450mm

About FSL 1610-450 STROKE WITH NEMA 23 (57HS56-3004A-123)JKL

Featured as a best-seller for automation, the FSL 1610-450 STROKE WITH NEMA 23 (57HS56-3004A-123)JKL delivers supreme performance with a 450mm stroke and NEMA 23 stepper motor. Boasting a step angle of 1.8 and superb holding torque of 1.26 Nm, this linear actuator features an incomparable precision-machined lead screw (16mm diameter, 10mm pitch) crafted from high-grade alloy steel. Designed for CNC, robotics, and 3D printing, enjoy remarkable savings on maintenance due to its robust build and high repeatability (0.01mm). Reliable and adaptable for versatile applications.

Application Method & Competitive Advantages

The FSL 1610-450 STROKE WITH NEMA 23 excels in CNC automation, 3D printing, robotics, and precise XY table positioning. It is suitable for integration into advanced manufacturing lines due to its high repeatability and robust build. Primary advantages include superb accuracy, effortless setup with standard end supports, and compatibility with microstepping drivers. This actuator is ideal for demanding applications that require reliable, high-precision linear motion and flexible integration across industrial settings.

Export Markets, Sample Requests & Certifications

Estimate quick order processing and seamless drop-off in primary export markets including North America, Europe, and Asia. Samples are available upon request for product qualification or test integration. The FSL 1610-450 STROKE WITH NEMA 23 is manufactured to adhere to international standards, ensuring quality and performance certifications. Trustworthy international logistics and export expertise guarantee prompt delivery, helping streamline your project timelines globally.

FAQ's of FSL 1610-450 STROKE WITH NEMA 23 (57HS56-3004A-123)JKL:

Q: How is the FSL 1610-450 STROKE WITH NEMA 23 installed and integrated into existing systems?

A: Installation is straightforward thanks to its standard end supports and 4-wire NEMA 23 connector. It is compatible with microstepping drivers and can be seamlessly incorporated into CNC, 3D printing, robotics, or XY table positioning systems.

Q: What applications benefit most from this actuator's features?

A: This actuator is ideal for applications requiring high precision and reliability, such as CNC automation, 3D printing, robotics, and automated positioning systems that demand repeatability up to 0.01mm.

Q: Where can I request a sample or place an order?

A: Samples and orders can be requested directly through the manufacturer, supplier, or authorized distributors. Contact sales teams for assistance in order processing and delivery estimates tailored to your region.

Q: When will my order be processed and shipped?

A: Once an order is confirmed, processing typically begins immediately. Shipping timelines are provided based on your location and order specifications, with efficient drop-off guaranteed through established logistics networks.

Q: What certifications assure the quality of this actuator?

A: The FSL 1610-450 STROKE WITH NEMA 23 is produced according to international quality and performance certifications, meeting or exceeding standards required for industrial and automation sectors.
