Vru 3105-cross Roller Table

Vru 3105-cross Roller Table Specification

Pressure
Designed for mechanical load applications, not pneumatic or hydraulic pressure.

Accuracy
5 microns (0.005 mm) repeatability for linear displacement.

Connection
Mounting holes provided for integration into precision assemblies.

Function
Provides precise linear motion utilizing crossed roller guides for high load-carrying capacity and superior accuracy.

Size
Available in various sizes, typical dimensions 50 mm x 120 mm x 20 mm (customized sizes available on request).

Surface Finish
Grinding finish for enhanced smoothness and wear resistance.

Load Capacity
Up to 30 kg depending on table size.

Application
Ideal for use in precision inspection instruments, optical devices, and automation systems.

Life Cycle
Rated for more than 10 million cycles under rated load.

Guide System
Integrated cross roller bearing system delivers smooth movement and extraordinary rigidity.

Operating Temperature
-20C to +80C.

Material
Constructed from high-grade hardened alloy steel and aluminum components.

Stroke Length
Standard stroke range from 30 mm to 150 mm.

Weight
Ranges from 0.5 kg to 4.2 kg, depending on model.

About Vru 3105-cross Roller Table

Order the first-rate VRU 3105-CROSS ROLLER TABLE today and secure an immaculate addition to your workspace at a true bargain. Expertly manufactured using high-grade hardened alloy steel and aluminum, this marvelous table offers a load capacity of up to 30 kg, standard stroke lengths between 30 mm and 150 mm, and grinding-finished surfaces for optimal smoothness and durability. The integrated cross roller bearing system ensures extraordinary rigidity and remarkable accuracy, perfect for professional applications. Available in several sizes, it boasts repeatability within 5 microns and over 10 million life cycles-order yours now!

Plant Applications and Surface Usability

The VRU 3105-CROSS ROLLER TABLE is widely implemented in manufacturing plants, research facilities, and precision tool rooms. Its finely finished surface is designed for compatibility with various inspection instruments and optical devices, supporting both specific and general use. Robust enough for demanding industrial scenarios, it excels on workbench surfaces, automated setups, and high-precision assembly lines, ensuring exact linear motion even in challenging environments.

Supply Ability, Safe Packaging & Sample Estimates

Benefit from our premium supply ability, ensuring timely delivery at the lowest price. Each VRU 3105-CROSS ROLLER TABLE is packaged with care to maintain its immaculate quality during transit. Samples are available upon request, and we provide accurate estimates for all orders. With a reputation as an exporter, importer, manufacturer, and supplier, we guarantee every customer receives nothing short of marvelous service and stellar product value.

FAQ's of VRU 3105-CROSS ROLLER TABLE:

Q: How does the VRU 3105-CROSS ROLLER TABLE achieve precise linear motion?

A: The table uses an integrated cross roller bearing system that provides smooth movement and extraordinary rigidity, supporting precise linear motion with a repeatability of 5 microns.

Q: What types of environments is this roller table suitable for?

A: It is ideal for precision inspection instruments, optical devices, and automation systems, functioning reliably in temperatures from -20C to +80C and various industrial settings.

Q: Where can I request a sample or place an order for the VRU 3105-CROSS ROLLER TABLE?

A: You can request a sample or order the table directly from us as your exporter, importer, manufacturer, and supplier. Contact us for competitive estimates and product availability.

Q: What benefits does the grinding surface finish offer for application surfaces?

A: The grinding surface finish enhances smoothness and wear resistance, making the table suitable for high-precision work, reducing friction, and extending the lifespan of the component.

Q: When should I consider using a cross roller table over other guide systems?

A: Choose the VRU 3105-CROSS ROLLER TABLE when your project demands superior load-carrying capacity, high accuracy, and extraordinary rigidity, particularly in setups where repeatable linear motion and durability are essential.
